EPDM/TPU扁平水管 EUF

Application:
Mainly used in shale oil gas, coal and other fields.
Features:
■ 3-ply manufacturing process which ensures the high adhesion strength and top fatigue resistance performance
■ Extreme chemical resistance performance on the inner surface:
based on ISO/TR7620 -2005 contrast test among TPU, Synthetic Rubber and NP, the performance of TPU and NP dropped dramatically, while Synthetic Rubber remain unchanged.
■ Extreme abrasion resistance property on the outer surface make the hose adapt to more working condition.
■ Outstanding diameter stability with high restored rate after be pressured thendepressured
■ Lager volume transfer performance of liquid
■ Being easy to deploy
Construction:
Tube: EPDM rubber.
Reinforcements: Polyester fiber
Cover: TPU.
Standard Color: Black, other color on request.
Standard length: 200m, other length on request
Temperature range: –40°C～+70°C

应用范围：
主要用于页岩气油，煤矿等领域，可输送水，采出水（回水）。
产品特性：
● 高粘合力和强抗裂性
● 内衬具有优秀的耐化学性能，可输送水，采出水（回水）
● 外表面有极好的耐磨性，适用于多种工作环境
● 施压前后，软管的口径保持极好的稳定性。
● 更大的液体传输能力
● 具有易折叠和易展开的操作方便性
软管结构:
内管: EPDM橡胶。
增强层：聚酯纤维。
外管: TPU外层。
标准颜色：黑色，其它颜色可以定制。
标准长度：200米，或者根据客户要求定制
适用温度: -40 to 70℃
