UPE食品级吸排软管 PUS
Applications:
Acid
and chemical suction and delivery, Suitable for 98% of existing chemicals.
Construction:
Tube:
Transparent UHMWPE (Ultra High Molecular Weight Polyethylene)
Reinforcement: High tensile
textile cords with embedded steel helix wire, antistatic copper wire.
Cover:
Blue EPDM - abrasion and ozone resistant
Temperature range: -20 °C~+90 °C
Standard/Approval: Meets FDA
使用范围:
有机溶剂和酸碱化学品的输送,市售化学品中98%均适用。
软管结构:
内管:透明UHMWPE(超高分子量聚乙烯)
增强层:高强力纤维编织及内置螺旋钢丝,带导电铜丝
外管:蓝色EPDM,耐磨损、耐老化、耐臭氧
温度范围:-20°C~+90°C
适用标准及认证:符合FDA标准
编码 | 内径 | 外径 | 弯曲半径 | 工作压力 | 爆破压力 | 真空 | 重量/米 | |
inch | mm | mm | mm | bar | bar | bar | Kg/m | |
PUS019 | 3/4" | 19 | 31 | 188 | 16 | 48 | 0.9 | 0.60 |
PUS025 | 1" | 25 | 37 | 225 | 16 | 48 | 0.9 | 0.73 |
PUS032 | 1-1/4" | 32 | 44 | 263 | 16 | 48 | 0.9 | 0.88 |
PUS038 | 1-1/2" | 38 | 51 | 338 | 16 | 48 | 0.9 | 1.01 |
PUS051 | 2" | 51 | 66 | 413 | 16 | 48 | 0.9 | 1.78 |
PUS063 | 2-1/2" | 63 | 79 | 450 | 16 | 48 | 0.9 | 2.39 |
PUS076 | 3" | 76 | 92 | 525 | 16 | 48 | 0.8 | 2.81 |
PUS102 | 4" | 102 | 118 | 675 | 16 | 48 | 0.8 | 3.87 |
